Product Introduction

PRODUCT
The company's traditional and AI model inference algorithms, developed on the CUDA parallel high-speed computing framework, incorporate multi-algorithm fusion. They are compatible with 8K monochrome cameras, 8K color cameras, 16K high-definition monochrome cameras, 16K high-definition color cameras, and line-scan cameras. Combined with multi-specification intelligent lighting technology, strobe technology, and unlimited  10-Gigabit fiber optic transmission technology, they achieve 3D imaging, color imaging, and ultra-high-definition imaging of material defects, to ensure efficient and accurate detection. The system can inspect both roll-to-roll (web materials) and sheet-to-sheet (sheet materials, including irregular ones). It is suitable for advanced manufacturing fields with stringent inspection requirements, such as semiconductors, new energy, papermaking, films, metals, electronic materials, and hygiene materials, delivering optimal solutions for stringent quality requirements.
/uploadfile/202511/cca45cda1008.png

Technical Parameters

PARAMETER
Industry Camera Accuracy Speed (max) Line Rate (max)
Hygienic Materials 8K Monochrome & Color 0.1~0.15mm/pixel 600m/min 100000line/sec
New Energy Materials 8K & 16K Monochrome 0.1~0.05mm/pixel 250m/min 84000line/sec
Optical Materials 8K & 16K Monochrome 0.1~0.045mm/pixel 350m/min 130000line/sec
Electronic Materials 8K & 16K Color 0.015~0.05mm/pixel 30m/min、80m/min 34000line/sec
Packaging Materials 8K & 16K Monochrome 0.1mm/pixel 650m/min 109000line/sec
Metal Materials 8K Monochrome & Color; 16K Monochrome & Color 0.025~0.05mm/pixel 60m/min、180m/min 60000line/sec
